TX-25 2.5 Tons Mini Excavator
TX-25 2.5-tons mini excavator is a highly versatile and efficient compact construction machine, designed to tackle a wide range of tasks with precision and power. Combining robust performance with exceptional maneuverability, this excavator is perfect for small to medium-sized projects where space and efficiency are critical.
Share:


The TX-25 2.5-ton mini excavator has proven itself a reliable, efficient, and usable machine, fitting the needs of all sorts of industries. Its compact build, strong performance, and easy-to-use features make it a must-have tool for projects that call for precision, agility, and power. Whether you’re on a construction site, or handling landscaping work, this mini excavator is built to get great results—all while boosting productivity and keeping costs down.





Technical Parameter

Weight & Bucket Size | |
---|---|
Operating weight: | 2460kg |
Bucket Capacity: | 0.066m³ |
Excavator Size | |
Overall Length: | 3750mm |
Overall height: | 2260mm |
Overall Width: | Shrunk Size 1300 mm Extended Size1500mm |
Undercarriage | |
Track Width: | 230mm |
Track Full - length: | 1600mm |
Engine Spec. | |
Engine Model: | Kubota D1105 |
Fuel Tank Capacity: | 28L |
Operational Performance | |
Bucket digging force: | 22KN |
Ground pressure: | 30kpa |
Maximum Digging Depth: | 2510mm |
Max digging height: | 3480mm |
Maximum Dump Height: | 2560mm |
Vertical Lifting Force: | 800kg |
Horizontal Lifting Force: | 520kg |
Maximum Digging Radius: | 4100mm |
Minimum Front - End Swing Radius ( Swing Arm in Motion): | 1850mm(1300mm) |
Minimum Rear - end Swing Radius: | 710mm |
Travel Speed (Low - speed, High - speed): | 2.6km/h,4.5km/h |
Slewing Speed : | 9.5revolutions per minute |
